Metal  Separator

 Separation as long as it is metal, such as iron, copper, stainless steel, aluminum, etc. The minimum metal is 0.3MM, and the sensitivity can be adjusted according to the actual production needs, microcomputer control, LED indication. Fast response and high accuracy. The machine is small in size, easy to install, and can be directly installed on the device. Used in food, plastics, packaging and other industries.

Scope of application:

Food industry: testing plastic raw materials. nozzle materials. powder, granules, popcorn, cornflakes, potato chips, nuts, fruits and noodle soup

Chemical industry: testing mixtures (can be directly removed from the metal)

Device Description

The metal separation system removes magnetic and non-magnetic metal impurities (steel, stainless steel, aluminum, etc.) from the free-falling bulk material through a turret funnel without any interference with product handling. This has proven to be a particularly effective method of removing impurities from grain, light, fragile and wet bulk materials.

1. Metal separator application characteristics

Testing products Large granular loose products

Dry, flowable, fine grain (particle diameter < 6 mm,

Fusion free fall and dumping

Conveyor plastic industry food industry chemical industry other industry

Typical range of metal separators for quality inspection of plastic pellets, mixtures or carbon-containing additives

2. Metal separator features:

As long as it is metal, it can be separated, such as iron, copper, stainless steel, aluminum, and so on. The minimum metal is 0.3MM, and the sensitivity can be adjusted according to the actual production needs, microcomputer control, LED indication. Fast response and high accuracy. The machine is small in size, easy to install, and can be directly installed on the device. Used in food, plastics, packaging and other industries.

Controller parameter

Detection part: German import

Control computer: Germany MEITLE

Start solenoid valve

Execution cylinder Japan SMC

Gas filter Japan SMC

Housing material: painted steel plate

Operating voltage: 220 VAC (+/- 10%) (with voltage selector switch), 50/60 Hz

Input current: 80/160 mA

Fuse: 2 315 mAh

Ambient temperature: -10/60 degrees

Protection level: IP65

Input terminals: test button, manual separation, reset, compressed air monitoring

Output terminal: counting, metal detection

3. Machine parameters

Compressed air: 4-8 kg, 6-8 mm hose connection

Air consumption: 0.4 liters per separation action

Protection level: IP54

Separation time: 0.2-2.5 seconds, 0-10 stepless adjustable detection accuracy

4. Equipment Advantages

Products containing long fibers do not block the discharge equipment.

Avoid disorder and product agglomeration (light and thin products)

Hygienic design, discharge device rustproof and waterproof

Avoid prolonged product accumulation and moldy mold

Quick and easy cleaning by cleaning the sheets

5. Sensitivity and yield
